Experience the future of home cinema with the 11.2-channel CX-A5200 AVENTAGE pre-amplifier. Yamaha’s renowned CINEMA DSP HD3 combined with Dolby Atmos® and DTS:X™ deliver an exhilarating home cinema experience.AVENTAGE 11.2-channel pre-amplifierSURROUND:AI automatically optimises the surround effect in real timeDolby Atmos and DTS:X with CINEMA DSP HD3HDMI® (7 in / 3 out) with Dolby Vision™ and Hybrid Log-GammaStudio-grade ESS DAC (ES9026 PRO x 2)MusicCast multi-room technology.

SPECIFICATIONSSurround Sound Processing:
Surround:AI     Yes
CINEMA DSP     Yes (HD3)
DSP Programs     34
Dialog Level Adjustment     Yes
Virtual Presence Speaker     Yes (with Virtual Rear Presence Speakers)
Virtual Surround Back Speaker     Yes
Dialogue Lift     Yes (no presence speakers required)
Dolby Atmos     Yes
Dolby TrueHD     Yes
Dolby Digital Plus     Yes
Dolby Digital     Yes
DTS:X     Yes
DTS-HD Master Audio     Yes
Audio Features:
File Format     MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz
Pure Direct     Yes (with video on mode)
Compressed Music Enhancer     Yes
High-resolution Music Enhancer     Yes
YPAO multi-point measurement     Yes with R.S.C. (Reflected Sound Control) , 3D, 64-bit High Precision EQ Calculation and Angle Measurement
YPAO Volume     Yes
Adaptive DRC (Dynamic Range Control)     Yes
Initial Volume & Maximum Volume Setting     Yes
A.R.T. Wedge     Yes
Audio Delay     Yes (0-500 ms)
DA Converter     ESS 384 kHz / 32-bit SABRE PRO Premier DAC™ ES9026PRO x 2 (for all channels incl. presence speakers)
Video Features:
4K Ultra HD Pass-through and upscaling     Yes (4K / 60p, 4:4:4)
HDMI 3D passthrough     Yes
HDMI eARC     Yes (via future firmware update)
HDMI Audio Return Channel     Yes
Component upconversion     Yes
HDMI upscaling     Yes (Analogue to HDMI / HDMI to HDMI)
Video adjustment     Yes
Deep Colour/x.v.Colour/24Hz Refresh Rate /Auto Lip-Sync     Yes
MusicCast Surround     Yes
HDMI Input/Output     7 / 3 (HDCP2.2, HDR10 / Dolby Vision / HLG and BT.2020 compatible)
HDMI CEC     Yes (SCENE, Device Control)
USB Input     USB Memory, Portable Audio Player
Network Port     Yes
Wi-Fi     Yes (2.4 / 5 GHz)
AirPlay     Yes
Bluetooth     Yes
Front AV Input     USB / Analogue Audio
Digital Audio Input/Output: Optical     3 / 0
Digital Audio Input/Output: Coaxial     3 / 0
Analog Audio Input/Output     XLR Balance: 1 / 0, RCA Unbalance: 9 (front 1) / 0
Phono Input     Yes
XLR Terminal     Yes
Component Video Input/Output     2 / 0
Composite Video Input/Output     4 / 0
Preout     XLR Balance: 11.2 ch, RCA Unbalance: 11.2 ch
Headphone Output     1
Tuner Section:
FM/AM Tuner     Yes (FM only)
DAB Tuner     Yes (Availability varies by region.)
User Interface:
On-screen display     Graphical User Interface
SCENE     SCENE PLUS (8 sets)
App Control     Yes (iPhone / iPad / Android phone / tablet)
Web Browser Control     Yes
Remote Control Unit     Yes (Full LED Backlight)
Zone Control:
Zone 2 Audio Output     Preout / HDMI
Zone 3 Audio Output     Preout
Zone 4 Audio Output     HDMI
Zone Video Output     HDMI / Component / Composite
Zone HDMI     Yes (Advanced HDMI Zone Switching)
Zone B Output     HDMI
Zone GUI     Yes
RS-232C Interface     Yes
+12V Trigger Output     2
Remote (IR) Input/Output     1 / 1
Party Mode     Yes
Standby Power Consumption (IR only)     ≤ 0.1W
Auto Power Standby     Yes
ECO mode     Yes
Dimensions (W x H x D)     435 x 193 x 474 mm (with antenna up: 435 x 270 x 474 mm)
Weight     15.2 kg.
